This product has stable performance, wide application range, and high cost-effectiveness. It can be widely used for continuous level measurement in industries such as steel, cement, chemical, power, environmental protection, food, and pharmaceuticals.
The high-frequency microwave pulses (radar waves) generated by the electronic units inside the radar are transmitted through the antenna system and propagate at the speed of light. When they encounter the surface of the measured medium, they are reflected and received by the recovery unit. The antenna receives reflected microwave pulses and transmits them to the electronic circuit. The microprocessor processes this signal and identifies the echoes generated by the micro pulses on the surface of the material. The correct recognition of echo signals is completed by intelligent software, with an accuracy of up to millimeter level.
Adopting advanced non-contact measurement
Flexible and diverse installation methods
The product supports multiple communication protocols
Can measure the level of all liquid and solid media with a dielectric constant>1.8
Measurement range 0-70m
Adopting a two-wire system and loop power supply technology, the power supply voltage and output signal are transmitted through a two core cable
4-20mA output or digital signal output
Resolution 2mm
Not affected by working conditions such as noise, steam, dust, vacuum, etc
Not affected by changes in medium density, viscosity, and temperature
The process pressure can reach 4MPa
The process temperature can reach 250 ℃
| Process connection | Flange/Material: 304 stainless steel, PP | ||
| Antenna profiles | PTFE | ||
| outer shell | Cast aluminum/stainless steel/ABS plastic | ||
| Seal between the outer casing and the outer casing cover | silicone rubber | ||
| Shell window | polycarbonate | ||
| Grounding terminal | Stainless steel | ||
| Power supply voltage | |||
| Four-wire system | (12-24)VDC | ||
| Maximum power consumption 80mA DC2 4V/2W | |||
| Allowed ripple | <100Hz | Uss<IV | |
| (100～100K)Hz | Uss<10mV | ||
| Dual-cavity shell | (198～242)VAC four-wire system | ||
| 110VAC four-wire system | |||
| Cable parameters | |||
| Cable inlet/plug | 1 M20x1.5 cable inlet | ||
| 1 blind block M20×1.5 | |||
| Terminal blocks | The cross-sectional area of the conductor is 2.5 mm². | ||
| Output parameters | |||
| Output signal | (4～20)mA/RS485Modbus | ||
| Resolution | 1mm | ||
| Fault signals | Current output remains unchanged: 20.5mA; 22mA; 3.9mA | ||
| Points Time | (0～20)s, adjustable | ||
| blind spot | 0.1m/0.2m/0.3m | ||
| Maximum measurement distance | 150 meters | ||
| Measurement interval | Approximately 1 second (depending on parameter settings) | ||
| Adjust time | Approximately 1 second (depending on parameter settings) | ||
| Working storage and transportation temperature | (-40～80)℃ | ||
| relative humidity | <95% | ||
| pressure | Max.2.5MPa | ||
Earthquake resistant | Mechanical vibration I0m/s², (10～150)Hz | ||
