Jingge has passed Chinese, Korean, and England standards, and 95% of its products are exported to Japan, Korea, the Middle East, South America, and parts of Europe. Our quality has earned the trust and recognition of customers worldwide. We will always be your most reliable partner.
Protective devices should be installed in environments with rapid pressure changes, vibration, or pulsation.
Do not apply pressure during transportation, installation, or use.
The equipment should be installed horizontally and vertically.
Normal pressure: Generally not exceeding 3/4 of the upper limit of the measurement value.
Alternating load: Not exceeding 2/3 of the upper limit of the measurement value.
Measurement of differential pressure between both sides of air filter
Differential pressure application line
Filter of gas line, Filtering line
※Checking whether the filter is stopped up or not
Diameter: 50,75,100mm
Accuracy
| Item | Classification | Mark |
| Accuracy | 2.0 grade | CL2.0 |
Scale Range/[unit:kpa]
0~50 to 1000
Material
Case :STS 304
Cover :Rubber
Dial :Aluminum
Connection:Aluminum
-PT⇔2-1/4(Female)
Max.Pressure
Aluminum:20Mpa
STS 316 :40Mpa
We're always here, ready to provide precise measurement solutions for your business. Kinger Instruments looks forward to establishing a long-term partnership with you, creating value and a shared future.
