运输及安装使用时不要施加压力
压力表应水平或垂直安装
正常压力：一般不超过测量上限值的3/4
交变负荷：不超过测量上限值的2/3
Petrochemical plants
Oil-hydraulic press
The place where the temperature changes on a largescale
Ship, power plant, Industrial, Special fuid line and etc
Diameter: 60,75,100,150 mm
Accuracy & Mounting Type
| Item | Classification | Mark |
| Accuracy | 1.0 grade | CL1.0 CL 1.6 |
| 1.5 grade | CL1.5 CL 2.5 | |
| Mounting Type | Botlom Connedion, Direct | A-TYPE |
| Bottom Cannedian, Surface | B-TYPE | |
| Badk Carnecion, Diredt | D-TYPE | |
| Badk Connection, Hush | BD-TYPE |
Scale Range)/[unit:Mpa]
Ø60,Ø75 :-0.1~2,-0.1~0,0~25
Ø100,Ø150:-0.1~2,-0.1~0,0~200
Material
Case &Cover :STS 304
Bourdon Tube:STS 304,STS 316
Movement :STS 304
Dial :Aluminum
Filling Liquid :Silicone or GLycerine
Connection :STS 316
-PT(NPT),PF⇔1/8,1/4,3/8,1/2
-UNF 7/16
